INR? (Internal State Change) Status Register Structure
The following table describes the states corresponding to the returned bit values:
Bit Value State
15 0 - Reserved for future use.
14 16384 1 - Probe was changed.
13 8192 1 - Trigger is ready.
12 4096 1 - Pass/Fail test detected desired outcome.
11 2048 1 - Waveform processing has terminated in trace F4.
10 1024 1 - Waveform processing has terminated in trace F3.
9 512 1 - Waveform processing has terminated in trace F2.
8 256 1 - Waveform processing has terminated in trace F1.
7 128 1 - A floppy or hard disk exchange has been detected.
6 64 1 - Floppy or hard disk has become full in AutoStore Fill mode.
5 32 0 - Reserved for LeCroy use.
4 16 1 - A segment of a sequence waveform has been acquired in acquisition memory but not yet read
out into the main memory.
3 8 1 - A time-out has occurred in a data block transfer.
2 4 1 - A return to the local state is detected.
1 2 1 - A screen dump has terminated.
0 1 1 - A new signal has been acquired in acquisition memory and read out into the main memory.
Note: On Teledyne LeCroy oscilloscopes, INR status bit 13 is set high when a trigger is armed, even
though the oscilloscope may not yet be ready to acquire due to technical limitations. If you are
concerned with timing a second action on the Trigger Ready state, it is safest to use the result of
the command TRMD SINGLE; WAIT;*OPC?, which will be 1 when the previous acquisition is fully
complete.
