Part 6: IEEE 488.2 Command Reference
EXR (Execution Error) Status Register Structure
The following table lists the error codes that may be returned with the EXR query. Codes marked with an
asterisk (*) are valid only on instruments with a removable hard drive or memory card.
Code Description
21 Permission error. The command cannot be executed in local mode.
22 Environment error. The oscilloscope is not configured to correctly process a command. For instance, the oscil-
loscope cannot be set to RIS at a slow timebase.
23 Option error. The command applies to an option which has not been installed.
24 Unresolved parsing error.
25 Parameter error. Too many parameters specified.
26 Non-implemented command.
27 Parameter missing. A parameter was expected by the command.
30 Hex data error. A non-hexadecimal character has been detected in a hex data block.
31 Waveform error. The amount of data received does not correspond to descriptor indicators.
32 Waveform descriptor error. An invalid waveform descriptor has been detected.
33 Waveform text error. A corrupted waveform user text has been detected.
34 Waveform time error. Invalid RIS or TRIG time data has been detected.
35 Waveform data error. Invalid waveform data have been detected.
36 Panel setup error. An invalid panel setup data block has been detected.
50* No mass storage present when user attempted to access it.
51* Mass storage not formatted when user attempted to access it.
53* Mass storage was write protected when user attempted to create a file, to delete a file, or to format the device.
54* Bad mass storage detected during formatting.
55* Mass storage root directory full. Cannot add directory.
56* Mass storage full when user attempted to write to it.
57* Mass storage file sequence numbers exhausted (999 reached).
58* Mass storage file not found.
59* Requested directory not found.
61* Mass storage file name not DOS compatible, or illegal file name.
62* Cannot write on mass storage because file name already exists.
