DDR?
Description
The DDR? query reads and clears the contents of the Device Dependent or Device Specific Error Register
(DDR). In the case of a hardware failure, the DDR register specifies the origin of the failure.
Query Syntax
DDR?
Response Format
DDR <value>
<value>:= 0 to 65535
DDR (Device Dependent) Status Register Structure
Bit Value Meaning
15...14 Reserved.
13 8192 Timebase hardware failure detected.
12 4096 Trigger hardware failure detected.
11 2048 Channel 4 hardware failure detected.
10 1024 Channel 3 hardware failure detected.
9 512 Channel 2 hardware failure detected.
8 256 Channel 1 hardware failure detected.
7 128 External input overload condition detected.
6...4 Reserved.
3 8 Channel 4 overload condition detected.
2 4 Channel 3 overload condition detected.
1 2 Channel 2 overload condition detected.
0 1 Channel 1 overload condition detected.
