Part 6: IEEE 488.2 Command Reference
SAVE/RECALL SETUP Commands and Queries
PANEL_SETUP?, PNSU?
Description
The PANEL_SETUP query returns all oscilloscope setups in ASCII format, which can be saved to an .LSS
file to be recalled to the oscilloscope using RECALL_SETUP.
Only setup data previously read by the PNSU? query or saved using the STORE_PANEL command can be
recalled into the oscilloscope. A panel setup error is generated if the setup data block contains invalid
data. See the Execution Error Status Register (EXR) table in EXR? for more information.
Note: The communication parameters (modified by commands CFMT, CHDR, CHLP, CORD and
WFSU) and the enable registers associated with the status reporting system (SRE, PRE, ESE, INE)
are not saved by this command.
Query Syntax
PANEL_SETUP?
Response Format
PANEL_SETUP <setup>
Related Commands
*RCL, *SAV
