MAUI Oscilloscopes Remote Control and Automation Manual
Operators Available with XDEV Option
These operators are standard on DDA/SDA/WavePro 7 Zi, and DDA/SDA/WaveMaster 8 Zi, and
LabMaster series oscilloscopes running XStreamDSO v. 8.0.0 or higher. They are available elsewhere with
the installation of the XDEV option.
Operator Additional Parameters Description
EXCELMATH(<source1>,<source2>) SOURCE1CELL,<cell>
SOURCE2CELL,<cell>
OUTPUTCELL,<cell>
SOURCE1HEADERCELL,<cell>
SOURCE2HEADERCELL,<cell>
OUTPUTHEADERCELL,<cell>
WITHHEADER, {ON, OFF}
OUTPUTENABLE, {ON, OFF}
SOURCE1ENABLE, {ON, OFF}
SOURCE2ENABLE, {ON, OFF}
NEWSHEET, {ON, OFF}
ADVANCED, {ON, OFF}
SCALING, {AUTOMATIC, MANUAL,
FROMSHEET}
{AUTOMATIC,MANUAL,FROMSHEET}
SPREADSHEETFILENAME,<
file
.xls>
Produces a waveform using a custom
Excel function, and outputs results to
Excel spreadsheet.
Use full path to spreadsheet file name.
FASTWAVEPORT(<source>) MAXSIZE,<value SAMPLE>,
TIMEOUT,<value S>,
PORTNAME,FASTWAVEPORT1
Produces a waveform using an external,
user-defined function.
MATLAB(<source1>,<source2>) MATLABCODE,<formula>
MATLABPLOT, {ON, OFF}
MATLABZEROOFFSET,<value>
MATLABSCALEPERDIV,<value>
Produces a waveform using custom
MATLAB function.
MCAD(<source1>,<source2>) SOURCE1VAR,<value>
SOURCE2VAR,<value>
OUTPUTVAR,<value>
SOURCE1HEADERVAR,<value>
SOURCE2HEADERVAR,<value>
OUTPUTHEADERVAR,<value>
WITHHEADER,{ON, OFF}
Produces a waveform using custom
MathCad function.
SCRIPT(<source1>,<source2) LANGUAGE,VBSCRIPT.
CODE,<VBScript code>,
TIMEOUT,<value>
Produces waveform from applied VBS
function.
6-96
