MAUI Oscilloscopes Remote Control and Automation Manual
PARAMETER_VALUE?, PAVA?
Description
The PARAMETER_VALUE query returns the current values of the waveform parameters for the specified
trace. Traces do not need to be displayed to obtain the values reported by PAVA?.
Query Syntax
To query measurement parameters:
<trace>:PAVA? [<parameter>...,<parameter>]
<parameter>:= any standard or user-defined parameter set with PACU
Note: TA through TD are for backward compatibility. Although accepted, they are not returned by
queries.
Response Format
<trace>:PAVA? <parameter>,<value>,<state>
Note: If <parameter> is not specified, or is equal to ALL, all standard voltage and time parameters
are returned followed by their values and states.
6-70
