User manual

Part 6: IEEE 488.2 Command Reference
Measurement Mnemonic Qualifiers
Eye opening factor EYEOPENFAC <source>
Eye negative overshoot EYEOVERN <source>
Eye positive overshoot EYEOVERP <source>
Eye peak noise EYEPKNOISE <source>
Eye peak-to-peak jitter EYEPKPKJIT <source>
Eye pulse width EYEPULSEWID <source>
Eye Q factor EYEQ <source>
Eye rise time EYERISETIME <source>
Eye RMS jitter EYERMSJIT <source>
Eye std. deviation noise EYESDNOISE <source>
Eye signal to noise EYESGTONOISE <source>
Eye suppression ratio EYESUPRATIO <source>
Eye width EYEWIDTH <source>
Jitter per duty-cycle
distortion
PERDCD <source>
Persistence duty-cycle PERDUTYCYC <source>
Per pulse symmetry PERPULSESYM <source>
PCIe misc. measurements PCIEMISC <source>
Note:
This measurement will need additional setup to return any-
thing but the default min. pulse time measurement.
PCIe min. pulse width TMNPLS <source>
PCIe uncorrelated pulse
width DJ
UPWJDD <source>
PCIe uncorrelated pulse
width TJ
UPWTJ <source>
All Other Options
For a description of other measurements made available by option key that may be settable using legacy
remote commands, download the software option manual from our website (see Resources).
The best test of compatibility is to set up the measurement as desired on the oscilloscope, then run the
PACU? query on that parameter. Whatever qualifiers are returned by the PACU? query are what can be set
using the PACU command. These may not be sufficient to fully configure the measurement. Use
Automation with the VBS command to set missing qualifiers.
6-65
