MAUI Oscilloscopes Remote Control and Automation Manual
XMath/SDA Option Measurements
These measurements are included on SDA 7 Zi and SDA 8 Zi series oscilloscopes running XStreamDSO
v. 8.0.0 or higher, or become available with the installation of an XMath or SDA option.
Note: In these cases, you will only be able to set the measurement and source using the PACU
command. Other qualifiers must be set manually or using Automation. Select an Eye Diagram as
the source for eye measurements.
Measurement Mnemonic Qualifiers
Edge displacement EDGEDA <source>
Pattern time PATTERNTIME <source>
Ring back high/low RING <source>
Lane-to-lane skew SD2SKEW <source>
Strip DDj from source STRIPDDJ <source>
Eye diagram zero level ZEROLVL <source>
SDA Option Measurements
These measurements are included on SDA 7 Zi and SDA 8 Zi series oscilloscopes running XStreamDSO
v. 8.0.0 or higher, or become available with the installation of an SDA option. As with the measurements in
the table above, you may not be able to set all necessary qualifiers using the PACU command.
Measurement Mnemonic Qualifiers
Eye AC rms EYEACRMS <source>
Eye power level ratio EXTRATIO <source>
Eye amplitude EYEAMPL <source>
Eye bit error rate estimate EYEBER <source>
Eye bit rate EYEBITRATE <source>
Eye bit time EYEBITTIME <source>
Eye crossing EYECROSSING <source>
Eye negative crossing EYECROSSN <source>
Eye positive crossing EYECROSSP <source>
Eye cyc area EYECYCAREA <source>
Eye delay EYEDELAY <source>
Eye delta delay EYEDELTDLY <source>
Eye fall time EYEFALLTIME <source>
Eye height EYEHEIGHT <source>
Eye mean EYEMEAN <source>
Eye one level EYEONE <source>
