User manual

MAUI Oscilloscopes Remote Control and Automation Manual
HDO6000 and Higher Bandwidth Oscilloscopes
These measurements are standard on HDO6000 and higher, MDA, WaveRunner 8000, WaveRunner/HRO
6 Zi, DDA/SDA/WavePro 7 Zi, DDA/SDA/WaveMaster 8 Zi, and LabMaster series oscilloscopes running
XStreamDSO v. 8.0.0 or higher.
Measurement Mnemonic Qualifiers
Histogram Mean AVG <source>
Math on Parameters CALCx <measure1>,<source1>,<operator>,<measure2>,<source2>
<operator>:= {ADD, SUB, MUL, DIV}
Cycles on screen CYCL <source>
Delta delay DDLY <source>
Delta trigger time DTRIG <source>
Delta width @ level DWIDLEV <source>,<slope>,<level PCT | level V>,<hysteresis DIV>
Duration of acquisition DUR <source>
Excel parameter EXCELPARAM
<source1var>,<source2var>,<outputvar>,<source1headervar>,
<source2headervar>,<outputheadervar>,<withheader>,
<outputenable>,<source1enable>,<source2enable>,
<newsheet>,<advanced>,'<worksheetfilename>'
Fall @ level FLEV <source>,<highlevel PCT | V>,<lowlevel PCT | V>
First (left-most) sample in
measure gate
FRST <source>
Histogram FWHM FWHM <source>
Histogram peak FW @ level FWxx <source>,<%maxpopulation PCT>
<%maxpopulation>:= value PCT of max population at which to
measure Full-Width
Half Period HPER <source>,<slope>,<level PCT | V>,<hysteresis DIV>
Histogram amplitude HAMPL <source>
Histogram base level HBASE <source>
Histogram right bin; same as
Histogram maximum
HIGH <source>
Histogram mean HMEAN <source>
Histogram median HMEDI <source>
Time clock edge to data edge
@ level
HOLDLEV /
HOLDTIME
<clocksource>,<clockslope>,<clocklevel PCT | V>,
<datasource>,<dataslope>datalevel PCT | V>,
<clockhysteresis DIV>,<datahysteresis DIV>
Histogram rms HRMS <source>
Histogram top level HTOP <source>
Last (right-most) sample in
measure gate
LAST <source>
6-62
