User manual

Part 6: IEEE 488.2 Command Reference
Measurement Mnemonic Qualifiers
Peak to peak PKPK <source>
Period PER <source>
Phase difference PHASE <source>
Rise time 10% to 90% RISE <source>
Rise time 20% to 80% RISE28 <source>
Root mean square RMS <source>
Time clock to clock edge SKEW <clocksource1>,<clockslope1>,<clocklevel1 PCT | V>,
<clocksource2>,<clockslope2>,<clocklevel2 PCT | V>,
<clockhysteresis1>,<clockhysteresis2>
Standard deviation SDEV <source>
Top TOP <source>
Width 50% positive slope WID <source>
Width 50% negative slope WIDN <source>
HDO4000 and Higher Bandwidth Oscilloscopes
These measurements are standard on HDO4000 and higher, MDA, WaveRunner 8000, WaveRunner/HRO
6 Zi, DDA/SDA/WavePro 7 Zi, DDA/SDA/WaveMaster 8 Zi, and LabMaster series oscilloscopes running
XStreamDSO v. 8.0.0 or higher.
Measurement Mnemonic Qualifiers
Delta period @ level DPLEV <signaltype>,<slope>,<level PCT | V>,<hysteresis DIV>,
<referencetype>,<-3dBfrequency HZ>,<frequency HZ>
Delta time @ level DTLEV <source1>,<slope1>,<level1 PCT | V>,<hysteresis1 DIV>
<source2>,<slope2>,<level2 PCT | V>,<hysteresis2 DIV>
Duty cycle @ level DULEV <source>
Edge @ level EDLEV <source>,<slope>,<level PCT | level V>,<hysteresis DIV>
Frequency @ level FREQLEV <signaltype>,<slope>,<level PCT | V>,<hysteresis DIV>,
<referencetype>,<-3dBfrequency HZ>,<frequency HZ>
Period @ level PLEV <signaltype>,<slope>,<level PCT | V>,<hysteresis DIV>,<refer-
encetype>,<-3dBfrequency HZ>,<frequency HZ>
Time @ level TLEV <source>,<slope>,<level PCT | V>,<hysteresis DIV>
6-61
