Measurements
Note: Measurements listed here may not be available on all instruments. If you do not already have
access to the measurement on the oscilloscope (Measure Setup selector), you will not have it via
remote control. See the product datasheet at teledynelecroy.com for a list of available
measurements.
Qualifiers shown in the tables below may take the following values and units. Notate the units as shown (V,
PCT, DIV, HZ, etc.).
<source>:= Header Paths and Sources. For histogram measurements, use histogram function Fn.
<level>:= value PCT or V
<slope>:= {POS, NEG}
<hysteresis>:= 0.01 to 8 DIV
<frequency>:= 10 to 1e9 HZ (Narrow Band center frequency)
<signaltype>:= {CLOCK, DATA}
<outputin>:= {TIME, UI}
<referencetype>:= {STANDARD, CUSTOM}
All MAUI Oscilloscopes
These measurements are standard on all MAUI oscilloscopes running XStreamDSO v. 8.0.0 or higher.
Measurement Mnemonic Qualifiers
Amplitude AMPL <source>
Area AREA <source>
Base BASE <source>
Delay DLY <source>
Duty cycle DUTY <source>
Fall time 90% to 10% FALL <source>
Fall time 80% to 20% FALL82 <source>
Frequency FREQ <source>
Maximum value MAX <source>
Mean value MEAN <source>
Minimum value MIN <source>
None/cleared NULL <source>
Overshoot negative OVSN <source>
Overshoot positive OVSP <source>
