Part 6: IEEE 488.2 Command Reference
PARAMETER_CUSTOM, PACU
Description
The PARAMETER_CUSTOM command configures user-defined parameters (My Measure) in locations P1
through Pn.
Tip: Use PAVA? to read the measured value of a parameter that was set up with PACU. The best
way to learn the required command syntax is to set up the measurement as desired on the
oscilloscope and run the Pn: PACU? query. The response will be formatted exactly as required,
especially if you have set the oscilloscope to suppress command headers using COMM_HEADER.
Command Syntax
PARAMETER_CUSTOM <parameter>,<measurement>,<qualifier>[,<qualifier>,...]
<parameter>:= 1 to n, CUST1 to CUST8
<measurement>:= mnemonic from table below or listed by the PAVA? query
<qualifier>:= qualifier(s) for each parameter shown in the tables below
Note: n represents the highest number parameter slot on your instrument. CUST1 through CUST8
are included for backward compatibility; they are accepted but not returned by queries.
Query Syntax
PACU? <parameter>
Response Format
PACU <parameter>,<measurement>,<qualifier>[,<qualifier>,...]
Related Commands
PARAMETER_DELETE, PARAMETER_VALUE
6-59
