Part 6: IEEE 488.2 Command Reference
The following table shows the command notation used to create the parameter-value pairs.
Parameters Mnemonic Values Mnemonic Notes
Trigger Type Dropout DROP
Edge EDGE
Glitch GLIT
Interval INTV
Pattern PA
Runt RUNT
Slew Rate SLEW
State Qualified SQ Add Qualifier Source parameter
Edge Qualified TEQ
Qualified First TEQ1
TV TV Unique syntax, see below
Single-source SNG For backward compatibility with leg-
acy oscilloscopes
Standard STD
Trigger Source SR C1 through Cn C1...Cn For best results, use C1 through C4
only. Use C2 and C3 for DBI acquis-
itions.
Auxilliary Line In LINE
External Trigger EX , EX5, EX10,
ETM10
See product datasheet for available
external trigger inputs.
Qualifier Source QL See Trigger Source
Hold Type HT Time greater than TI Holdoff is not available for SNG and
STD triggers.
Time less than TL
Events EV
Pulse larger than PL
Pulse smaller than PS
Pulse width P2 Add HV and HV2
Interval larger than IL
Interval smaller than IS
Interval width I2 Add HV and HV2
No hold-off on wait OFF
First Hold Value HV <value><unit> Holdoff is not available for SNG and
STD triggers.
Second Hold Value HV2 <value><unit>
