User manual

MAUI Oscilloscopes Remote Control and Automation Manual
Short Long What The Command or Query Does
DSST
DD_SHOW_SAMPLE_TIMES
Shows vertical-line cursors on the grid at each sample time
corresponding to the read clock.
DST
DD_SAM_THRESH Sets the SAM threshold value for channel emulation.
DSTR
DD_STORE_REFERENCE Stores the head signal to one of the DDA’s available memories for ana-
log compare and channel emulation with reference.
DTF
DD_TRAIN_FILTER Commands the DDA to determine reasonable values for each filter
parameter.
DVSP
DD_VCO_SYNCH_PATTERN Defines the number of bits per half-period in the synchronization
field.
DVTD
DD_VCOSYNCH_TO_DATA Specifies the number of bytes on the analog head signal waveform
between the end of the VCO sync field and the actual data.
ET-PMT (Option) - Electrical Telecomm Pulse Mask Testing
Short Long What The Command or Query Does
CU_OPT?
CUSTOM_OPTIONS? Returns installed custom options.
CUAP
CUSTOM_APPLICATION Toggles between Mask Tester mode and oscilloscope mode.
MTFA
MT_FAIL_ACTION Sets fail actions.
MTOF
MT_OFFSET Sets the offset for STM-1E, STS-3E, and 139M.
MTOP?
MT_OPC? Returns state of last operation.
MTPC?
MT_PF_COUNTERS? Returns pass/fail result.
MTST
MT_SELECT_TEST Selects Electrical Telecomm testing standard.
MTSY?
MT_SYMBOL? Returns 1 or 0 symbol, or pos or neg.
MTTS
MT_TEST_STATE Controls testing status: RUN, STOP, PAUSE, CONTINUE.
MTVA
MT_VERTICAL_ALIGN Performs offset alignment for STM-1E, STS-3E, and 139M.
6-14
