MAUI Oscilloscopes Remote Control and Automation Manual
STORAGE
Short Long What The Command or Query Does
DELF
DELETE_FILE Deletes files from mass storage directory.
TRFL
TRANSFER_FILE Allows for transferring files to and from storage media, or between
oscilloscope and computer.
WAVEFORM TRANSFER - Preserving and Restoring Waveforms
Short Long What The Command or Query Does
INSP?
INSPECT? Allows acquired waveform parts to be read.
REC
RECALL Recalls waveform from mass storage to internal memory.
STO
STORE Stores a waveform in internal memory or mass storage.
STST
STORE_SETUP Controls the way in which waveforms are stored.
TMPL?
TEMPLATE? Produces a copy of the template describing a complete waveform.
WF
WAVEFORM Query transfers a waveform from oscilloscope to controller in re-load-
able format; command transfers a waveform read using WF? from
controller to scope.
WFSU
WAVEFORM_SETUP Specifies amount of waveform data to go to controller.
DISK DRIVE ANALYSIS (Option) — Specialized Disk Drive Measurements
Short Long What The Command or Query Does
3DB
DD_CTAF_3DB Sets the CTAF parameter, 3 dB.
DACT
DD_ANALOG_COMP_THRESH
Sets the analog threshold value for DDA analog compare.
DARD
DD_ANALYZE_REGION_DISABLE Disables the use of the DDA analyze region markers.
DARL
DD_ANALYZE_REGION_LENGTH Selects the length of a region to be analyzed by DDA.
DARS
DD_ANALYZE_REGION_START Selects the start of a region to be analyzed by DDA.
DBIT
DD_BITCELL Enters the bit cell time of the drive head signal.
DBST
DD_CTAF_BOOST Sets the DDA CTAF parameter, boost.
DBYT
DD_BYTE_OFFSET Moves the head trace to show the specified byte in DDA.
DDFC
DD_CTAF_FC Sets the DDA CTAF parameter, cut-off frequency fc.
DDFM
DD_FIND_METHOD Selects the DDA error-finding method.
DDSI
DD_SIGNAL_INPUT Sends or reads out the association of a particular Disk Drive signal
with a source.
DENC
DD_ENCODING Allows selection of the data-encoding ratio for locating the bytes by
byte offset in DDA.
DERI?
DD_ERR_INFO? Returns the measured value associated with the last DDA error pos-
ition selected, and a code specifying what the value contains.
6-12
