User manual

Part 6: IEEE 488.2 Command Reference
PROBES - Using Probes
Short Long What The Command or Query Does
PRIT?
PROBE_INFOTEXT? Returns attributes of a connected probe.
PRNA?
PROBE_NAME Identifies a probe connected to the instrument.
PRx:AZ
PRx:AUTOZERO Initiates an AutoZero cycle in an ADP30x probe.
PRx:BWL
PRx:BANDWIDTH_LIMIT Sets the upper (HF) –3 dB bandwidth limit of an ADP305 probe.
PRx:CPL
PRx:COUPLING Selects the coupling mode of an ADP30x probe.
PRx:OFST
PRx:OFFSET Sets the probe offset value of an ADP30x probe.
PRx:VDIV
PRx:VOLT_DIV Sets the vertical sensitivity at an ADP30x probe input.
SAVE/RECALLSETUP - Perserving and Restoring Panel Settings
Short Long What The Command or Query Does
PNSU?
PANEL_SETUP? Returns panel setups in ASCIIformat.
*RCL
*RCL Recalls one of five non-volatile panel setups.
RCPN
RECALL_PANEL Recalls a panel setup from mass storage.
*RST
*RST Initiates a device reset.
*SAV
*SAV Stores current state in non-volatile internal memory.
STPN
STORE_PANEL Stores a panel setup to mass storage.
STATUS - Obtaining Status Information and Setup Service Requests
Short Long What The Command or Query Does
ALST?
ALL_STATUS? Reads and clears the contents of all status registers.
*CLS
*CLS Clears all status data registers.
CMR?
CMR? Reads and clears the CoMmand error Register (CMR).
DDR?
DDR? Reads and clears the Device Dependent Register (DDR).
*ESE
*ESE Sets the Standard Event Status Enable register (ESE).
*ESR?
*ESR? Reads and clears the Event Status Register (ESR).
EXR?
EXR? Reads and clears the EXecution error Register (EXR).
INE
INE Sets the INternal state change Enable register (INE).
INR?
INR? Reads and clears INternal state change Register (INR).
IST?
IST? Reads the current state of the IEEE 488.
*OPC
*OPC Sets the OPC bit in the Event Status Register (ESR).
*PRE
*PRE Sets the PaRallel poll Enable register (PRE).
*SRE
*SRE Sets the Service Request Enable register (SRE).
*STB?
*STB? Reads the contents of the IEEE 488.
*WAI
*WAI WAIt to continue - required by the IEEE 488.
6-11
