User manual

Part 6: IEEE 488.2 Command Reference
COMMUNICATION - Setting Communication Characteristics
Short Long What The Command or Query Does
CFMT
COMM_FORMAT Selects the format for sending waveform data.
CHDR
COMM_HEADER Controls formatting of query responses.
CHL
COMM_HELP_LOG Returns the contents of the RC Assistant log.
CHLP
COMM_HELP Controls operational level of the RC Assistant.
CORD
COMM_ORDER Controls the byte order of waveform data transfers.
CURSOR - Performing Measurements
Short Long What The Command or Query Does
CRMS
CURSOR_MEASURE Specifies the type of cursor/parameter measurement.
CRS
CURSORS Sets the cursor type.
CRST
CURSOR_SET Allows positioning of any cursor.
CRVA?
CURSOR_VALUE? Returns trace values measured by specified cursors.
OFCT
OFFSET_CONSTANT Sets offset to be fixed in either divisions or volts.
PACL
PARAMETER_CLR Clears all current parameters in Custom, Pass/Fail.
PACU
PARAMETER_CUSTOM Controls parameters with customizable qualifiers.
PADL
PARAMETER_DELETE Deletes a specified parameter in Custom, Pass/Fail.
PARM
PARAMETER Controls the parameter mode, Standard, Custom, etc.
PAST?
PARAMETER_STATISTICS? Returns parameter statistics results.
PAVA?
PARAMETER_VALUE? Returns current parameter, mask test values.
PECS
PER_CURSOR_SET
Positions one of the six independent cursors.
PF
PASS_FAIL Sets up pass fail system.
PFDO
PASS_FAIL_DO Defines outcome and actions for Pass/Fail tests.
DISPLAY - Displaying Waveforms
Short Long What The Command or Query Does
DISP
DISPLAY Controls the display screen.
DTJN
DOT_JOIN Controls the interpolation lines between data points.
GRID
GRID Specifies single-, dual- or quad-mode grid display.
HMAG
HOR_MAGNIFY Horizontally expands the selected expansion trace.
HPOS
HOR_POSITION Horizontally positions intensified zone's center.
INTS
INTENSITY Controls the brightness of the grid.
MSG
MESSAGE Displays a character string on the instrument screen.
PECL
PERSIST_COLOR Controls color rendering method of persistence traces.
6-9
