User manual

MAUI Oscilloscopes Remote Control and Automation Manual
Commands and Queries by Subsystem
ACQUISITION - Controlling Waveform Captures
Short Long What The Command or Query Does
ARM
ARM_ACQUISITION Changes acquisition state from stopped to single.
ASET
AUTO_SETUP Adjusts vertical, timebase and trigger parameters.
ATTN
ATTENUATION Selects the vertical attenuation factor of the probe.
BWL
BANDWIDTH_LIMIT Enables/disables bandwidth-limiting low-pass filter.
COMB
COMBINE_CHANNELS Controls the channel interleaving function.
CPL
COUPLING Selects the specified input channel's coupling mode.
FRTR
FORCE_TRIGGER Forces the instrument to make one acquisition.
ILVD
INTERLEAVED Enables/disables Random Interleaved Sampling (RIS).
MSIZ
MEMORY_SIZE Selects max. memory length.
OFST
OFFSET Allows output channel vertical offset adjustment.
RCLK
REFERENCE_CLOCK Toggles between internal clock and external clock.
SCLK
SAMPLE_CLOCK Toggles between internal clock and external clock.
SEQ
SEQUENCE Controls the sequence mode of acquisition.
STOP
STOP Immediately stops signal acquisition.
TDIV
TIME_DIV Modifies the timebase setting.
TRCP
TRIG_COUPLING Sets the coupling mode of the specified trigger source.
TRDL
TRIG_DELAY Sets the time at which the trigger is to occur.
*TRG
*TRG Executes an ARM command.
TRLV
TRIG_LEVEL Adjusts the trigger level of the specified trigger source.
TRMD
TRIG_MODE Specifies the trigger mode.
TRPA
TRIG_PATTERN Defines a trigger pattern.
TRSE
TRIG_SELECT Selects the condition that will trigger acquisition.
TRSL
TRIG_SLOPE Sets the trigger slope of the specified trigger source.
VDIV
VOLT_DIV Sets the vertical sensitivity.
WAIT
WAIT Prevents new analysis until current is completed.
AUTOMATION - Sending Automation Commands
Short Long What The Command or Query Does
VBS
VBS Sends Automation commands.
6-8
