Part 6: IEEE 488.2 Command Reference
Short Long Subsystem What The Command or Query Does
TRMD
TRIG_MODE ACQUISITION Specifies the trigger mode.
TRPA
TRIG_PATTERN ACQUISITION Defines a trigger pattern.
TRSE
TRIG_SELECT ACQUISITION Selects the condition that will trigger acquisition.
TRSL
TRIG_SLOPE ACQUISITION Sets the trigger slope of the specified trigger source.
*TST?
*TST? MISC Performs internal self-test.
VBS
VBS AUTOMATION Sends an automation command.
VDIV
VOLT_DIV ACQUISITION Sets the vertical sensitivity.
VMAG
VERT_MAGNIFY DISPLAY Vertically expands the specified trace.
VPOS
VERT_POSITION DISPLAY Adjusts the vertical position of the specified trace.
*WAI
*WAI STATUS WAIt to continue - required by the IEEE 488.
WAIT
WAIT ACQUISITION Prevents new analysis until current is completed.
WF
WAVEFORM WAVEFORM
TRANSFER
Transfers a waveform from controller to scope.
WFSU
WAVEFORM_SETUP WAVEFORM
TRANSFER
Specifies amount of waveform data to go to controller.
6-7
