User manual

MAUI Oscilloscopes Remote Control and Automation Manual
Short Long Subsystem What The Command or Query Does
PAVA?
PARAMETER_VALUE? CURSOR Returns current parameter, mask test values.
PECL
PERSIST_COLOR DISPLAY Controls color rendering method of persistence traces.
PECS
PER_CURSOR_SET CURSOR Positions one of the six independent cursors.
PELT
PERSIST_LAST DISPLAY Shows the last trace drawn in a persistence data map.
PERS
PERSIST DISPLAY Enables or disables the persistence display mode.
PESA
PERSIST_SAT DISPLAY Sets the color saturation level in persistence.
PESU
PERSIST_SETUP DISPLAY Selects display persistence duration.
PF
PASS_FAIL CURSOR Sets up pass fail system.
PFDO
PASS_FAIL_DO CURSOR Defines outcome and actions for Pass/Fail
PNSU
PANEL_SETUP SAVE/RECALL Complements the *SAV/*RST commands.
*PRE
*PRE STATUS Sets the PaRallel poll Enable register (PRE).
*RCL
*RCL SAVE/RECALL Recalls one of five non-volatile panel setups.
RCLK
REFERENCE_CLOCK ACQUISITION Toggles between internal clock and external clock.
RCPN
RECALL_PANEL SAVE/RECALL Recalls a front panel setup from mass storage.
*RST
*RST SAVE/RECALL Initiates a device reset.
*SAV
*SAV SAVE/RECALL Stores current state in non-volatile internal memory.
SCDP
SCREEN_DUMP HARD COPY Initiates a screen capture.
SCLK
SAMPLE_CLOCK ACQUISITION Toggles between internal clock and external clock.
SEQ
SEQUENCE ACQUISITION Controls the sequence mode of acquisition.
*SRE
*SRE STATUS Sets the Service Request Enable register (SRE).
*STB?
*STB? STATUS Reads the contents of the IEEE 488.
STO
STORE WAVEFORM
TRANSFER
Stores a trace in internal memory or mass storage.
STOP
STOP ACQUISITION Immediately stops signal acquisition.
STPN
STORE_PANEL SAVE/RECALL Stores front panel setup to mass storage.
STST
STORE_SETUP WAVEFORM
TRANSFER
Sets up waveform storage.
TDIV
TIME_DIV ACQUISITION Modifies the timebase setting.
TMPL?
TEMPLATE? WAVEFORM
TRANSFER
Produces a complete waveform template copy.
TRA
TRACE DISPLAY Enables or disables the display of a trace.
TRCP
TRIG_COUPLING ACQUISITION Sets the coupling mode of the specified trigger source.
TRFL
TRANSFER_FILE WAVEFORM
TRANSFER
Transfers ASCII files to and from storage media, or
between scope and computer.
TRDL
TRIG_DELAY ACQUISITION Sets the time at which the trigger is to occur.
*TRG
*TRG ACQUISITION Executes an ARM command.
TRLV
TRIG_LEVEL ACQUISITION Adjusts the trigger level of the specified trigger source.
6-6
