MAUI Oscilloscopes Remote Control and Automation Manual
Commands and Queries by Short Form
Short Long Subsystem What The Command or Query Does
3DB
DD_CTAF_3DB DDA Sets the CTAF parameter, 3 dB.
ACAL
AUTO_CALIBRATE MISC Enables and disables automatic calibration.
ALST?
ALL_STATUS? STATUS Reads and clears the contents of all status registers.
ARM
ARM_ACQUISITION ACQUISITION Changes acquisition mode from Stopped to Single.
ASET
AUTO_SETUP ACQUISITION Adjusts vertical, timebase and trigger parameters.
ATTN
ATTENUATION ACQUISITION Selects the vertical attenuation factor of the probe.
BUZZ
BUZZER MISC Controls the buzzer in the instrument.
BWL
BANDWIDTH_LIMIT ACQUISITION Enables/disables bandwidth-limiting low-pass filter.
*CAL?
*CAL? MISC Performs a complete internal calibration of the instru-
ment.
CFMT
COMM_FORMAT COMM Selects the format for sending waveform data.
CHDR
COMM_HEADER COMM Controls formatting of query responses.
CHL
COMM_HELP_LOG COMM Returns the contents of the RC Assistant log.
CHLP
COMM_HELP COMM Controls operational level of the RC Assistant.
CLM
CLEAR_MEMORY FUNCTION Clears the specified memory.
*CLS
*CLS STATUS Clears all status data registers.
CLSW
CLEAR_SWEEPS FUNCTION Restarts the cumulative processing functions.
CMR?
CMR? STATUS Reads and clears the CoMmand error Register (CMR).
COMB
COMBINE_CHANNELS ACQUISITION Controls the channel interleaving function.
CORD
COMM_ORDER COMM Controls the byte order of waveform data transfers.
COUT
CAL_OUTPUT MISC Sets signal type put out at the CAL connector.
CPL
COUPLING ACQUISITION Selects the specified input channel's coupling mode.
CRMS
CURSOR_MEASURE CURSOR Specifies the type of cursor/parameter measurement.
CRS
CURSORS CURSOR Sets the cursor type.
CRST
CURSOR_SET CURSOR Allows positioning of any cursor.
CRVA?
CURSOR_VALUE? CURSOR Returns trace values measured by specified cursors.
CUAP
CUSTOM_APPLICATION ET-PMT Toggles between Mask Tester and oscilloscope mode.
CU_OPT?
CUSTOM_OPTIONS? ET-PMT Returns installed custom options.
DACT
DD_ANALOG_COMP_THRESH DDA Sets the analog threshold value for Analog Compare.
DARD
DD_ANALYZE_REGION_DISABLE DDA Disables the use of the analyze region markers.
DARL
DD_ANALYZE_REGION_LENGTH DDA Selects the length of a region to be analyzed.
DARS
DD_ANALYZE_REGION_START DDA Selects the start of a region to be analyzed.
DATE
DATE MISC Changes the date/time of the internal real-time clock.
