Part 3: Automation Control Variable Reference
app.SaveRecall.Remote
CVARs defining the scope and format of exported waveform data.
Actions
Action Description
app.SaveRecall.Remote.DoExport Used internally by MAUI to implement legacy style remote waveform
transfer. Do not use.
app.SaveRecall.Remote.DoImport Used internally by MAUI to implement legacy style remote waveform
transfer. Do not use.
3-27
