MAUI Oscilloscopes Remote Control and Automation Manual
app.PassFail.Qn
CVARs related to individual Pass/Fail test qualifiers Q1-Qn. Not available on WaveSurfer and HDO4000
oscilloscopes.
Child Objects
Object Description
app.PassFail.Q
n
.Operator Settings related to test operator.
Actions
Action Description
app..PassFail.Qn.ClearSweeps
Clears sweeps.
app..PassFail.Qn.Operator.ClearSweeps
Clears sweeps.
app.PassFail.Q
n
.Operator.FindLimit When qualifier is performing a parameter comparison (Condi-
tion = Param compare), sets the maximum value in Operator
Limit field.
app.PassFail.Q
n
.Operator.FindLimitUsing
n
Sigma When qualifier is performing a parameter comparison (Condi-
tion = Param compare), sets the value in Operator Limit field
using
n
Sigma.
n
:= {1, 3, 5}
3-22
