Part 3: Automation Control Variable Reference
app.PassFail
CVARs related to Pass/Fail testing and test Qualifiers Q1-Qn.
Names of the forms app.PassFail.PassFail("Qremote").xxxx and app.PassFail.PassFail("Qn").xxxx are alias
Collections. For example:
l app.PassFail.PassFail("Qremote").Operator is equivalent to app.PassFail.Qremote.Operator
l app.PassFail.PassFail("Qn").Out.Result is equivalent to app.PassFail.Qn.Out.Result
Child Objects
Object Description
app.PassFail.Qn
Settings related to test qualifier.
app.PassFail.LastPass Returns last passed result. See
Result Interface
reference.
app.PassFail.NumPass Returns number of results passed. See
Result Interface
reference.
app.PassFail.Rate Returns Pass Fail rate. See
Result Interface
reference.
Actions
Action Description
app.PassFail.ClearSweeps
Clears accumulated data for single function trace.
3-21
