User manual

Part 3: Automation Control Variable Reference
app.Math.Fn and app.Math.XY
CVARs related to individual math functions F1-Fn and XY trace.
Child Objects
Object Description
app.Math.F
n
.Operator
n
Setup This node is dynamically created and will contain the controls for the
operator currently selected into Operator
n
.
app.Math.F
n
.Zoom Function zoom scale settings.
Actions
Action Description
app.Math.Fn.ClearSweeps
app.Math.XY.ClearSweeps
Clears accumulated data for single function trace.
Clears persistence X-Y plot.
app.Math.F
n
.DoResetZoom Resets scale of F
n
trace to 1:1.
app.Math.F
n
.DoStoreToMemoryTrace Stores F
n
trace to corresponding internal memory (e.g., F1 to M1).
app.Math.F
n
.FPHit Opens/closes the F
n
dialog display. Each successive invocation of the
command acts like a toggle.
app.Math.F
n
.ShowProcessingWeb Open WebEditor window to create processing web to run in function.
Not available on WaveSurfer and HDO4000 oscilloscopes.
app.Math.F
n
.Operator
n
Setup.DownFactor For those operators that involve a sampling factor (such as Inter-
polation), decreases the sample value by one step.
app.Math.F
n
.Operator
n
Setup.UpFactor For those operators that involve a sampling factor (such as Inter-
polation), increases the sample value by one step.
3-17
