MAUI Oscilloscopes Remote Control and Automation Manual
app.LabNotebook
CVARs related to the LabNotebook documentation tool.
Note: In MAUI, LabNotebook CVARS have been moved to the File > Save and File > Recall dialogs.
See app.SaveRecall.
Actions
Action Description
app.LabNotebook.CreateReport Outputs selected Notebook Entries in report format.
app.LabNotebook.DeleteAll Deletes all Notebook Entries.
app.LabNotebook.DeleteRecord Deletes selected Notebook Entries.
app.LabNotebook.DeviceChanged Used internally by MAUI to propagate Windows "Device Changed"
notifications to LabNotebook. Do not use.
app.LabNotebook.EmailRecord Emails selected Notebook Entries.
app.LabNotebook.ExtractAttachmentsNow
Extracts external files attached to selected LabNotebook to path set
in app.LabNotebook.ExtractFilepath.
app.LabNotebook.ExtractFilesNow Extracts screen capture (.PNG), setup (.LSS) and trace (.TRC) files
that make up the Notebook Entry into separate files.
app.LabNotebook.FilterRecords Applies search filters to list of Notebook Entries.
app.LabNotebook.FlashBackToRecord Invokes Flashback Recall of selected Notebook Entry. The flash-
back restores the screen image, waveforms, and setups saved with
the entry.
app.LabNotebook.InternalView Opens the Labnotebook Report Viewer, displaying the selected
entry in the report format.
app.LabNotebook.NextRecord Displays the next Notebook Entry
app.LabNotebook.PreviousRecord Displays the previous Notebook Entry
app.LabNotebookPrintRecord Sends selected Notebook Entry to connected printer.
app.LabNotebook.Refresh Refreshes the list of Notrbook Entries for the selected LabNote-
book file. Primarily used by legacy LabNotebook for WaveSurfer
and WaveRunner Xi oscilloscopes.
app.LabNotebook.ReportGenRefreshFromCurrentState Generates report using current state of oscilloscope (all setups, vis-
ible waveforms, visible table data, etc.).
app.LabNotebook.Save Saves current state of oscilloscope to new Notebook Entry.
app.LabNotebook.SaveReport Saves contents of report window to file using current
app.LabNotebook.Report* settings.
app.LabNotebook.ShowEditDescription Displays pop-up of Notebook Entry Description for editing.
app.LabNotebook.ShowEMailMenu Displays Email & Report Settings dialog.
app.LabNotebook.ShowScreenImageSettings Displays pop-up of Screen Image settings for editing (linked to
Area/Color Preferences button).
app.LabNotebook.ViewRecord Displays selected Notebook Entry in report window.
3-14
