Part 3: Automation Control Variable Reference
app.History
CVARs related to the oscilloscope History Mode feature. Not available on Zi series oscilloscopes.
Child Objects
Object Description
app.History.HistoryTable Settings related to the History Mode tabular display.
Actions
Action Description
app.History.Next
Displays next acquisition in history.
app.History.Previous Displays previous acquisition in history.
app.History.HistoryTable.ClearSweeps Clears history buffer.
3-13
