User manual

Part 3: Automation Control Variable Reference
app.Acquisition.Cn
CVARs related to input channels C1 through Cn.
app.AcquisitionPMU.SEn contains equivalent CVARs for SAM40 sensor acquisition module channels.
Names of the form app.Acquisition.Channels.xxxx are an alias Collection. For example:
l app.Acquisition.Channels("Cn") is equivalent to app.Acquisition.Cn
l app.Acquisition.Channels(n) is equivalent to app.Acquisition.Cn
l app.Acquisition.Channels("Cn").Out.Result is equivalent to app.Acquisition.Cn.Out.Result
Child Objects
Object Description
app.Acquisition.C
n
.InputB On WaveMaster, LabMaster, and equivalent DDA/SDA oscilloscopes, set-
tings related to the "B" row inputs.
Actions
Action Description
app.Acquisition.C
n
.ClearSweeps
Clears all accumulated sweeps for channel.
app.Acquisition.C
n
.FindScale Automatically adjusts channel's V/div and Offset such that the signal is
visible on the screen within +/- 3 div.
app.Acquisition.C
n
.HorScaleToggle Toggles Horizontal Offset control between (1, 2, 5) stepped and fine incre-
ment input. Var. checkbox is cleared or checked.
app.Acquisition.C
n
.VerScaleToggle Toggles Vertical Scale control between (1, 2, 5) stepped and fine incre-
ment input. Var. checkbox is cleared or checked.
3-7
