2.41 PD_VDM_DisplayPort_Configure_Message
PD_VDM_DisplayPort_Configure_Message packet template contains all the fields of
PD_VDM_Structured_Header but default value for NumberOfDataObjects field is 2 and default
value for VDMCommand field is PD_VDM_COMMAND_DISPLAYPORT_CONFIGURE and default value for
VDMSVID field is PD_DISPLAY_PORT_SVID. Following are additional data fields for this packet
template:
Field Name
Description
ConfigureVdo
Contains only one VDO in type of
PD_VDM_DisplayPort_Configure_VDO packet template.
2.41.1 PD_VDM_DisplayPort_Configure_VDO
Used as ConfigureVdo for PD_VDM_DisplayPort_Configure_Message packet template. Available data
fields for this packet template are:
Field Name
Description
SelectConfiguration
Default: PD_DISPLAYPORT_CONFIGURATION_USB
Signaling
Default: 0x00
Reserved_DPC_1
Default: 0x00
UFPU_PinAssignment
Default: 0x00
Reserved_DPC_2
Default: 0x00
2.42 PD_VDM_DisplayPort_Configure_Response
PD_VDM_DisplayPort_Configure_Response packet template contains all the fields of
PD_VDM_Structured_Header but default value for VDMCommand field is
PD_VDM_COMMAND_DISPLAYPORT_CONFIGURE and default value for VDMSVID field is
PD_DISPLAY_PORT_SVID and default value for VDMCommandType is
PD_VDM_COMMAND_TYPE_RESPONDER_ACK.
2.43 PD_ExtMsgHeaders
Applied to Rev3.0. PD_ExtMsgHeaders packet template contains all the fields of
PD_ControlMessage but the default value of Extended field is 1. Following are the additional
fields for this packet template:
Field Name
Description
DataSize
Default: 0x00
Reserved
Default: 0x00
RequestChunk
Default: 0x00
ChunkNumber
Default: 0x00
Chunked
Default: 0x00
2.44 PD_SourceCapExtendedMsg
Applied to Rev3.0. PD_SourceCapExtendedMsg packet template contains all the fields of
PD_ExtMsgHeaders but the default value of MessageType field is 1 and the default value of
DataSize field is 0x17. Following are the additional fields for this packet template(these
additional fields blong to PD_SourceCapExtDataBlock packet template):
Field Name
Description
