2.20.2 PD_PowerDataObjectVariableSupply_Sink
Used as SinkCapabilitiesData for PD_SinkCapabilitiesMessage. Available fields for this packet
template are:
Field Name
Description
OperationalCurrent_10mAUnits
Default: 0
MinVoltage_50mVUnits
Default: 0
MaxVoltage_50mVUnits
Default: 0
PowerDataType
Default: 2
2.20.3 PD_PowerDataObjectBatterySupply_Sink
Used as SinkCapabilitiesData for PD_SinkCapabilitiesMessage. Available fields for this packet
template are:
Field Name
Description
OperationalPower_250mWUnits
Default: 0
MinVoltage_50mVUnits
Default: 0
MaxVoltage_50mVUnits
Default: 0
PowerDataType
Default: 1
2.21 PD_RequestPacket
PD_RequestPacket packet template contains all the fields of PD_ControlMessage but default
value for MessageType is 2 and default value for NumberOfDataObjects field is 1. Following are
additional data fields for PD_RequestPacket packet template:
Field Name
Description
Data
This field can contain only one RDO packet variables. RDO types which can
assign to this field are:
PD_RequestDataObject_Fixed_Variable_NoGiveBack,
PD_RequestDataObject_Fixed_Variable_GiveBack,
PD_RequestDataObject_Battery_NoGiveBack,
PD_RequestDataObject_Battery_GiveBack
2.21.1 PD_RequestDataObject_Fixed_Variable_NoGiveBack
Used as data for PD_RequestPacket. Available fields for this packet template are:
Field Name
Description
MaxOperatingCurrent_10mAUnits
Default: 0
OperatingCurrent_10mAUnits
Default: 0
Rsvd1
Default: 0
UnchunkedExtMsgSupported
Default: 0
Rev3.0 only
NoUsbSuspend
Default: 0
UsbCommunicationsCapable
Default: 0
CapabilityMismatch
Default: 0
GiveBackFlag
Default: 0
ObjectPosition
Default: 1
Rsvd2
Default: 0
