Data Sheet

106
rderedSetType
Indicates the ordered set type. Possible values:
PD_ORDERED_SET_TYPE_SOP
PD_ORDERED_SET_TYPE_SOP_PRIME
PD_ORDERED_SET_TYPE_SOP_DOUBLE_PRIME
selectedSvid
Indicates the SVID
modeId
Indicates the mode index related to the specified SVID
$Vdo
Vendor defined data object. Should be from PD_VDO(Inherited from PD_Generic_VDO) type.
Field Name
Description
Data
VDO data
Result
User can evaluate the command results(including sub-results) using IfMatched/ElseMatched
command.
Result Value
Description
PD_RESULT_OK
Command succeeded
PD_RESULT_FAILED
Command failed. In this case corresponding sub
results for PD_SendPacket are valid also (depends
on the error type which has been occurred during
sending data).
Examples
$vdo = PD_VDO
{
Data = 0x00
}
call PD_AttentionVdo(PD_ORDERED_SET_TYPE_SOP, 0xFF01, 1, $vdo)
5.1.94 PD_SetDiscoveryProcessSetting
Applies settings to DiscoveryProcess command. It must be called before
PD_PerformDiscoveryProcess to take effect.
Format
Call PD_SetDiscoveryProcessSetting(PD_DiscoveryProcess_Settings $settings)
Parameters
$settings
Should be from PD_DiscoveryProcess_Settings type. Table below describes the
PD_DiscoveryProcess_Settings template:
Field Name
Description
Discover_SOP_PP_During_SOP_P
Indicates whether perform SOP Double Prime discovery
during SOP Prime discovery process or not. Possible Values:
PD_TRUE
PD_FALSE(Default)
SkipEnterMode
Indicates whether to skip the EnterMode phase or not.
Default: PD_FALSE
Result
