Datasheet

Powerful Triggering
For difficult problems a simple edge
or logic level trigger is not enough.
LogicStudio advanced triggering
provides an environment for creating
powerful combinations of edge,
logic level, parallel bus and serial bus
triggers to isolate difficult problems.
Timing Cursors
Quickly measure the time between
transitions on a single line, across
digital lines or from a digital line to
an analog waveform. Snap the cursors
directly to the waveform edge for
precise measurements.
Digital, Serial, Analog
Connect a WaveJet 300A to the
same PC as the LogicStudio 16
and turn the PC into a Mixed Signal
Oscilloscope displaying digital, serial
and analog signals simultaneously.
LogicStudio will display all digital,
serial and analog signals on the PC
display and allow you to get a full
picture of your embedded system.
3
Easy Channel Setup
Quickly configure the inputs,
signal type, name and the color
on the fly for all 16 channels from
the signals screen or change a
single line on the fly from the main
screen. Double-click a channel to
create a unique name that applies
to your device.
Serial Data Protocol
Decode and Trigger
Decode I
2
C, SPI and UART
serial data busses and view
the appropriate clock and data
signals directly below the protocol
message. Isolate specific data
patterns or addresses by triggering
directly on that data.
Waveform Magnifier
Get a better view of the waveforms
by passing over them with the
magnifier, scroll the mouse
wheel to zoom in for an even
closer look. The magnifier shows
waveform details in a long capture
without having to change the
horizontal scale.
ADVANCED FEATURES, SIMPLE DEBUG
ADVANCED FEATURES, SIMPLE DEBUG
