Key Features
•
100 MHz, 1 GS/s,
16 channels
•
I
2
C, SPI, UART
protocol analysis
•
History mode
•
Timing cursors
•
Oscilloscope
connectivity
•
Waveform magnifier
•
Powerful trigger
environment
•
Communicate
with colleagues
Logic analyzers are known to be slow, complicated and
expensive but LogicStudio™ changes all this by delivering
a powerful feature set, high-performance hardware and
an intuitive point and click user-interface. With timing
cursors, history mode, I
2
C, SPI and UART decoding,
powerful triggering and simple navigation the PC is
transformed in to an all-in-one debug machine.
The intuitive user-interface works with basic mouse operations. To pan the
waveforms simply click and drag, use the mouse wheel to zoom in or scan
the waveforms with the magnification toll to get a great view of the details.
With all the debug tools accessible from the main screen, debugging is
simple, efficient and just one mouse click away.
LogicStudio provides even more
functionality when a WaveJet™ 300A
oscilloscope is connected to the PC.
Analog waveforms from the oscilloscope
are displayed alongside the digital
and serial waveforms captured by
LogicStudio turning the PC in to a mixed
signal oscilloscope. This combination
of waveforms provides insight that a
traditional logic analyzer cannot.
