USB Flash Drive and Device Ports
6. If printing fai
ls, check that the USB cable is connected to the PictBridge port
on the printer, and try again.
NOTE. The oscilloscope stores these settings until you change them, even if you
push the Default Setup button, or you power off the oscilloscope.
NOTE. To stop sending the screen image to the printer, pus h Abort Printing.
74 TBS1000 Series Oscilloscopes User Manual
