USB Flash Drive and Device Ports
In these situat
ions, click Cancel to exit the Found New Hardware wizard.
Do NOT allow the wizard to finish.
Unplug the USB
cable from your oscilloscope, and install the software.
Reconnect your oscilloscope to t he PC and follow steps 7a, 7b, and 7c.
8. When prompted, click Finish.
9. If Windows asks you to insert a CD, click Cancel.
10. Run the PC Communications software on your PC.
11. If the oscilloscope and PC do not communicate, refer to the PC
Communications online help and documentation.
Connecting to a GPIB System
If you want to communicate between the oscilloscope and a GPIB system, use a
TEK-USB-488 adapter and follow t hese steps:
1. Connect the oscilloscope to a TEK-USB-488 adapter with a USB cable.
The Accessories appendix has information on how to order a n adapter. (See
page 123, Accessories.)
2. Connect the TEK-USB-488 adapter to your GPIB system with a GPIB cable.
3. Push
the Utility ► Option ► GPIB Setup ► Address option button to
select the appropriate address for the adapter, or use the multipurpose knob.
The default GPIB address is 1.
4. Run your GPIB software on your GPIB system.
5. If t
he oscilloscope and your GPIB system do not communicate, refer to the
information on the software for your GPIB system, and to the user manual for
the TEK-USB-488 adapter to resolve the problem.
Command Entry
NOTE. For complete command information, refer to the TBS1000, TDS2000C and
TPS2000 Series Digital Oscilloscopes Programmer Manual, 077-0444-XX.
72 TBS1000 Series Oscilloscopes User Manual
