Getting Started
USB Flash Drive
port for file storage
Direct printing to any PictBridge compatible printer
PC communications through the USB D evice port with OpenChoice PC
Communications software
Connect to a GPIB controller through an optional TEK-USB-488 adapter
Cursors w ith readouts
Trigger frequency readout
Sixteen automatic measurements
Waveform
averaging and peak detection
Dual time base
Math functions: +, -, and × operations
Math Fast Fourier Transform (FFT)
Pulse Width trigger capability
Video trigger capability with line-selectable triggering
Exter
nal trigger
Variable persistence display
User interface and help topics in ten languages
Ins
tallation
Power Cord
Use only the power cord provided with your oscilloscope. Appendix B:
Accessories lists the standard and the optional accessories.
Po
wer Source
Use a power source that delivers 90 t o 264 VAC
RMS
,45to66Hz. Ifyouhavea
400 Hz power source, it must deliver 90 to 132 VAC
RMS
, 360 to 440 Hz.
Security Loop
Use a standard laptop computer security lock, or thread a security cable through
the built-in cable channel to secure your oscilloscope to your location.
2 TBS1000 Series Oscilloscopes User Manual
