Getting Started
TBS1000 Series Digital Storage Oscilloscopes are small, lightweight, benchtop
instruments, which you can use to take ground-referenced measurements.
This chapter describes how t o do the following tasks:
Install your product
Perform a brief functional check
Perform a probe check and compensate probes
Match your probe attenuation factor
Use t he self calibration routine
NOTE. You can select a language to display on the screen when you p ower on the
oscilloscope. At any time, you can also access the Utility ► Language option to
select a language.
General Features
The next table and list d escribe the general features.
Model Channels Bandwidth Sample rate Display
TBS1022
225MHz
500 MS/s Color
TBS1042
240MHz
500 MS/s Color
TBS1062
260MHz
1 GS/s Color
TBS1064
460MHz
1 GS/s Color
TBS1102
2 100 MHz
1 GS/s Color
TBS1104
4 100 MHz
1 GS/s Color
TBS1152
2 150 MHz
1 GS/s Color
TBS1154
4 150 MHz
1 GS/s Color
Context-sensitive help system
Color LCD display
Selectable 20 MHz bandwidth limit
2500 point record length for each channel
Autoset
Autoranging
Probe Check Wizard
Setup and waveform storage
TBS1000 Series Oscilloscopes User Manual 1
