Preface
Preface
This manual c
ontains operating information for the TBS1000 Series Digital
Storage Oscilloscopes.
Help System
The oscilloscope has a Help system with topics that cover all the features of the
oscilloscope. You can use the Help system to display several kinds o f information:
General information about understanding and using the oscilloscope, such
as Using the Menu System.
Information about specific menus and controls, such as the Vertical Position
Control.
Advice about problems you may face while using an oscilloscope, such as
Reducing Noise.
The Help sys tem provides several ways to find the information you need:
context-sensitive help, hyperlinks, and an index.
Context-Sensitive Help
The os
cilloscope displays information about the last menu displayed on the
screen when you push the Help front-panel button. When viewing help topics,
an LED lights next to the multipurpose knob to indicate that the knob is active.
If the topic uses more than one page, turn the multipurpose knob to move from
page to page within the topic.
Hyperlinks
Most of the help topics contain phrases marked with angle brackets, such as
<Autoset>. These are links to other topics. Turn the multipurpose knob to move
the highlight from one link to another. Push the Show Topic o ption button to
display the topic corresponding to the highlighted link. Push the Back option
b
utton to return to the previous topic.
Index
Push the front-panel Help button, then push the Index option button. Push the
Page Up or Page Down option b uttons until you find the index page that contains
the topic you want to view. Turn the multipurpose knob to highlight a help topic.
Push the Show Topic option button to display the topic.
NOTE. Push the Exit option button or any menu button to remove the Help text
from the screen and return to displaying waveforms.
TBS1000 Series Oscilloscopes User Manual xiii
