Appendix B: TPP0101 and TPP0201 Series 10X Passive P robes Information
Do Not Operate i
n Wet/Damp Conditions.
Do Not Operate in an Explosive Atmosphere.
Keep Product Surfaces Clean and Dry.
Safety Terms and Symbols
Terms in This Manual.
These terms
may appear in this manual:
WARNING. Warning statements identify conditions or practices that could result
in injury or loss of life.
CAUTION. Caution statements identify conditions or practices that could result in
damage to this product or other property.
Symbols on the Product. These symbols may appear on the product:
TBS1000 Series Oscilloscopes User Manual 121
