Appendix B: TPP0101 and TPP0201 Series 10X Passive P robes Information
Performance G
raphs
Table 9: Certifications and compliances
Characteristics Description
EC Declaration of
Conformity
Compliance was demonstrated to the following specification as listed
in the Official Journal of the European Communities:
Low Voltage Directive 2006/95/EC:
EN61010-031: 2002
Safety Standards
UL61010-031;2007
CAN/CSA C22.2 N o. 61010-031-07
IEC61010-031; IEC 61010-031/A1:2008
TBS1000 Series Oscilloscopes User Manual 119
