Compliance Information
Australia / New Zealand
Declaration of
Conformity – EMC
Complies with t
he EMC provision of the Radiocommunications Act per the
following standard, in accordance with ACMA:
CISPR 11 :2003
. Radiated and Conducted Emissions, Group 1, Class A, in
accordance with EN 61326-1:2006 and EN 61326-2-1:2006.
