Reference
Remove Wavefor
m. To remove a waveform from the display, push a channel
menu front panel button. For example, push the 1 (channel 1 menu) button to
display or remove the channel 1 waveform.
NOTE. You do not have to display a channel waveform to use it as a trigger
source or for math operations.
NOTE. You must display a channel waveform to take measurements from it, use
cursors o n it, or to save it as a Reference waveform or to a file.
TBS1000 Series Oscilloscopes User Manual 105
