General safety summary
Termsinthismanual
These terms may
appear in this manual:
WARNING. Warning statements identify conditions or practices that could result
in injury or loss of life.
CAUTION. Caution statements identify conditions or practices that could result in
damage to this product or other property.
Symbols and terms on the
product
These terms may appear on the product:
DANGER in
dicates an injury hazard immediate l y accessible as you read
the marking.
WARN IN G
indicates an injury hazard not immediately a ccessible as you
read the marking.
CAUTIO
N indicates a hazard to property including the product.
The following symbol(s) may appear on the product:
vi TBS1000 Series Oscilloscopes User Manual
