Reference
Function Setting
Vertical coup
ling
DC (if GND was previously selected); A C for a video signal;
otherwise, unchanged
VOLTS/DIV
Adjusted
The Autoset function examines all channels for signals and displays c orresponding
waveforms. Autoset also determines the trigger source based on the following
conditions:
If multiple channels have signals, the oscilloscope displays the channel with
the l owest frequency signal.
If no signals are found, then the oscilloscope displays the lowest-numbered
channel when Autoset was invoked.
If no signals are found and no channels are displayed, then the oscilloscope
displays and uses channel 1.
When you use Autoset and the oscilloscope cannot determine the signal type, the
oscilloscope adjusts the horizontal and the vertical scales, then takes the Mean
and Pk-to-Pk automatic me asurements.
The Autoset function is usually more useful than Autorange in the following
situations:
Troubleshooting one stable signal
Automatically seeing measurements of your signal
Easily changing how the signal is presented. For example, viewing only one
cycle o f the waveform, or the rising edge of the waveform
Viewing video signals or FFT signals
Sine Wave
When you use the Autoset function and the oscilloscope determines that the signal
is similar to a sine wave, the oscilloscope displays the following options:
Sine wave Details
Multi-cycle sine
Displays several cycles with appropriate vertical and
horizontal scaling; the oscilloscope displays Cycle
RMS, Frequency, Period, and Peak-to-Peak automatic
measurements
Single-cycle sine
Sets the horizontal scale to display about one cycle
of the waveform; the oscilloscope displays Mean, and
Peak-to-Peak automatic measurements
FFT
Converts the input time-domain signal into its frequency
components and displays the result as a graph of
frequency versus magnitude (spectrum); because this is a
mathematical calculation, refer to the Math FFT chapter
for more information
Undo Autoset
Causes the oscilloscope to recall the previous setup
