Datasheet

Service options
Opt. D1 Calibration Data Report
Probes and accessories are not covered by the oscilloscope warranty and Service Offerings. Refer to the datasheet of each probe and accessory model for its unique warranty
and calibration terms.
Probe option
TBS1XX2B P2220 Replaces standard probes with P2220 probes (200 MHz passive voltage probes with 1x/ 10x attenuation)
Standard accessories
Accessory
Description
Passive probes, one per channel TPP0051: 50MHz passive probe for: TBS1052B
TPP0101: 100 MHz passive probe for: TBS1072B, TBS1102B
TPP0201: 200 MHz passive probe for: TBS1152B, TBS1202B
Power cord (Please specify plug option)
NIM/NIST Traceable certificate of calibration
Printed documentation Installation and safety manual
(English, Japanese, and Simplified Chinese)
CD with customer documentation Customer documentation including detailed user manuals (English, French, German, Italian, Japanese, Korean,
Portuguese, Russian, Simplified Chinese, Spanish, Traditional Chinese)
5-year warranty Covers labor and parts for defects in materials and workmanship for 5 years, excluding probes and accessories
(probes and accessories are not covered by the oscilloscope warranty and service offerings. refer to the data sheet
of each probe and accessory model for its unique warranty and calibration terms)
Recommended accessories
Accessory
Description
TEK-USB-488 GPIB-to-USB converter
AC2100 Soft carrying case for instrument
HCTEK4321 Hard plastic carrying case for instrument (requires AC2100)
RM2000B Rackmount kit
077-0444-xx Programmer manual – English only
077-0772-xx Service manual – English only
174-4401-xx USB host to device cable, 3 ft. long
Recommended probes
Probe
Description
TPP0051 10X passive probe, 50 MHz bandwidth
TPP0101 10X passive probe, 100 MHz bandwidth
TPP0201 10X passive probe, 200 MHz bandwidth
P2220 1X/10X passive probe, 200 MHz bandwidth
P6101B 1X passive probe (15 MHz, 300 V RMS CAT II rating)
P6015A 1000X high-voltage passive probe (75 MHz)
P5100A 100X high-voltage passive probe (500 MHz)
P5200A 50 MHz, 50X/500X high-voltage differential probe
P6021A 15 A, 60 MHz AC current probe
