PC/WINDOWS SOFTWARE

Setting up a PostScript driver for Windows NT 3.5 and 3.51

Note The Windows NT driver does not support the PhaserMatch application. Refer to Which Windows driver to

install? for information on drivers that do.

You may need your original Windows NT setup diskettes (or CD-ROM) to complete this procedure.

1. If your computer has an Intel-compatible processor, such as the Intel I386, go on to Step 2.

If your computer is a MIPS, Alpha, or PowerPC, edit the

PRINTER.INF

ﬁle (located in the

WIN95_95

directory on the printer’s CD-ROM or in the top level of the Windows 95/NT diskette).

a. Copy these ﬁles to a new, formatted diskette,

placing them at the top (root) level of the

new diskette.

TEK1

PRINTER.INF

TKPH6001.PPD

Standard conﬁguration

TKP600P1.PPD

Extended Features option

Note Press and hold down the printer’s button on the front panel for conﬁguration information.

b. Open the copy of the

PRINTER.INF

ﬁle on the new diskette in a text editor such as Notepad.

c. Locate the following section in the

PRINTER.INF

ﬁle:

[ProductType]

STF_PLATFORM = I386
