FRONT PANEL MESSAGES
594
Close Top Cover Close the top cover; you may need to fully open and then close the
cover and its latch.
Close Exit Cover Close the exit cover.
Close Ink Loader Close the cover on the ink loader.
Lock Top Cover Make sure that the latch on the top cover is locked.
Empty Waste Bin Remove, empty, and reinsert the waste bin.
Service Required
Fault Code:xx
Turn the printer off, wait at least 15 seconds and turn the printer’s
power on again. If the failure persists, note the code number in the
display. In the U.S., call Tektronix service at 1-800-835-6100.
Outside the U.S., contact your local Tektronix office.
Ink Loader Low This message appears when the ink loader has two or fewer ink
sticks of a particular color. Open the cover of the ink loader and
load ink sticks of that color.
<color> Ink Low This message appears when ink loader is empty of a particular
color. The printhead stops printing if ink is not loaded soon. Open
the cover of the ink loader and load ink sticks of that color.
Front panel messages (cont'd.)
Message Action
