9
Regulatory Information and Specifications
9-8
Phaser 380 Color Printer
Specifications
Printer tilt
Place the printer on a level surface with no more than 2¡ tilt in any direction.
Equivalent to raising one corner of the printer approximately 16 mm
(0.625 in.).
Caution
Tilting the printer more than 2¡ causes drum ßuid to leak from
the maintenance tray resulting in damage to your printer not
covered by the printerÕs warranty.
Temperature
Operating: 15¡ C to 35¡ C (59¡ F to 95¡ F)
Nonoperating: Ð30¡ C to +60¡ C (Ð22¡ F to 140¡ F)
Storage: Ð30¡ C to +60¡ C (Ð22¡ F to 140¡ F)
Humidity
Operating: 10% to 80% Relative Humidity, noncondensing
Nonoperating: 10% to 95% Relative Humidity, noncondensing
Altitude
Operating: 0 to 2,400 meters (0 to 8,000 feet)
Nonoperating: 0 to 15,000 meters (0 to 50,000 feet)
Primary voltage ranges
87 Ð 128 VAC, 115 VAC nominal 174 Ð 250 VAC, 220 VAC nominal
Frequency range
48 to 66 Hz
AC input ratings
115 VAC, 12 Amps 220 VAC, 6 Amps
Print quality and Pages Per Minute (ppm) speed
Left and right margins for Letter-size media set to 7.3 mm (0.29 in.) or larger.
∆
Tabloid Maximum transparency supported only from the manual-feed slot.
Fast Color
mode
Standard
mode
Enhanced
mode
A4/Letter-size paper
3.5 ppm 2.5 ppm 1.2 ppm
A4/Letter-size transparency
Not
supported
1.5 ppm 0.64 ppm
A3/Tabloid Maximum-size paper
∆
2.0 ppm 1.3 ppm 0.6 ppm
