Supplies, Accessories, and Expanding Your Printer 8
User Manual 8-3
Interface cables and adapters
The following cables and adapters are available through Tektronix or your
dealer. Contact your dealer for other cables and adapters.
Printer interface cables and adapters
Order number Description Connectors and cable length
012-1468-00 Parallel cable 36-pin high-density plug to 25-pin DSUB plug;
3 meters (9.84 feet)
Connects the printer’s parallel port to a PC or workstation parallel port.
013-0299-00 Parallel/Centronics adapter parallel adapter: converts 36-pin low-density IEEE
1284-B plug to 36-pin high-density IEEE 1284-C plug
Adapts your system’s existing low-density, Centronics parallel cable connector to the printer’s
high-density parallel connector.
012-1465-00 SCSI-2 HD to SCSI-1 LD cable 50-pin high-density plug to 50-pin low-density plug;
2.0 meters (6.56 feet)
Connects the printer’s SCSI port to a hard disk drive or the Phaser Copystation SCSI port.
012-1299-00 SCSI-1 LD to Macintosh SCSI cable 50-pin low-density plug to Macintosh SCSI 25-pin plug
Combine with 013-0297-00 to connect the printer’s SCSI port to a hard disk drive with
Macintosh SCSI 25-pin plug.
013-0297-00 SCSI-1 LD to SCSI-2 HD adapter SCSI adapter: converts 50-pin low-density plug to
50-pin high-density plug
Use with either 012-1465-00 or 012-1299-00 to convert a low-density SCSI connection to a
high-density SCSI connection.
012-1379-00 Serial (RS-232) Null modem cable 9-socket receptacle to 9-socket receptacle;
1.8 meters (6 feet)
Connects the printer’s serial port to a PC or workstation serial port.
012-1380-00 Serial (RS-232) Null modem cable 9-socket receptacle to 25-socket receptacle;
1.8 meters (6 feet)
Connects the printer’s serial port to a PC or workstation serial port.
