Appendix A: Specifications (AWG710)
A-36 AWG710&AWG710B Arbitrary Waveform Generator User Manual
Table A-42: Function Generator (FG)
Characteristics Description
Operation Mode Continuous mode only
Waveform Shape Sine, Triangle, Square, Ramp, Pulse, DC
Frequency 1.000 Hz to 400.0 MHz
Amplitude
Range 0.020 V
p–p
to 2.000 V
p–p
, into a 50 Ω load
( OPTION02 : 0.5 V
p–p
to 1.0 V
p–p
, into a 50 Ω load )
Resolution 1 mV
Offset (except option 02)
Range -0.500 V to +0.500 V, into a 50 Ω load
Resolution 1 mV
DC Level (except option 02) DC waveform only
Range -0.500 V to +0.500 V, into a 50 Ω load
Resolution 1 mV
Polarity Normal, Inverted
Duty
Range 0.1 % to 99.9 %
Resolution Frequency Resolution
1.000 Hz to 4.000 MHz 0.1 %
4.001 MHz to 20.00 MHz 0.5 %
20.01 MHz to 40.00 MHz 1.0 %
40.01 MHz to 80.00 MHz 2.0 %
80.01 MHz to 100.0 MHz 2.5 %
100.1 MHz to 160.0 MHz 4.0 %
160.1 MHz to 200.0 MHz 5.0 %
200.1 MHz to 400.0 MHz 10.0 %
Marker Out
Pulse Width
Mrker1 Hi : 0 % to 20 % of 1 waveform period
Lo : 20% to 100 % of 1 waveform period
Marker2 Hi : 0 % to 50 % of 1 waveform period
Lo : 50 % to 100 % of 1 waveform period
Hi : 0 % to 52 % of 1 waveform period
Lo : 52 % to 100 % of 1 waveform period at frequency range is 100.1MHz to 160.0MHz
Level
Hi 2.0 V min into a 50 Ω load
Lo 0 V max into a 50 Ω load
